SuperBase M Series Portable Power Station - Smaller, Lighter, Quieter
ZENDURE| SuperBase M 1,000Wh Portable Power Station
Tiny, Portable, Space-Saving: The smallest 1000Wh power station in the market, 62% Smaller, 43% lighter than similar brands.
Fan-less, Super Quiet: Less than 30dB, SuperBase M is whisper-quiet for a peaceful night"s sleep.
Car-friendly: SuperBase M easily fits on the center console of most vehicles. And a full charge is just ten hours away using the 12.6V/8A car charging port.
Power Multiple Devices at Once: With 2*AC ports, 1*100W PD USB-C port, 3*12W USB-A ports, 1*126W car socket port, 2*DC ports, it"s capable of powering 9 devices at once.
1,000W/600W AC Output: You can easily power home appliances and charge handheld essentials at the same time.
Tech Specs
SuperBase 1000M |
SuperBase 600M |
|
Capacity |
1016Wh |
607Wh |
Battery Cells |
Lithium-ion cells |
Lithium-ion cells |
Dimensions |
325 x 190 x 138mm |
280mm x 190mm x 138mm |
Weight |
8.3kg |
6.4kg |
Solar Input |
18-24V Input 160W Max |
18-24V Input 160W Max |
DC Input |
18-24V 120W Max |
18-24V 120W Max |
Type-C Input |
PD100W |
PD100W |
Car Socket Input |
12.6V/8A, 100.8W Max |
12.6V/8A, 100.8W Max |
AC Output |
1000W Total (Surge 1500W) |
600W Total (Surge 1000W) |
DC Output |
USB-A*3: 5V/2.4A, 30W Total;Type-C: PD100W; Car Socket Port Output*1: 12.6V/10A, 126W Max;DC5521*2: 12.6V/6A (126W Max Total) |
USB-A*3: 5V/2.4A, 30W Total;Type-C: PD100W; Car Socket Port Output*1: 12.6V/10A, 126W Max;DC5521*2: 12.6V/6A (126W Max Total) |
LED Lamp |
1st Mode: 5W Max; 2nd Mode:10W MAX;3rd Mode: SOS; 4th Mode: Warning light burst. |
1st Mode: 5W Max; 2nd Mode:10W MAX;3rd Mode: SOS; 4th Mode: Warning light burst. |
Temperature |
Discharge: -10°C to 40°C;Charge: 0°C to 45°C |
Discharge: -10°C to 40°C;Charge: 0°C to 45°C |
Display |
LCD Display |
LCD Display |
Tiny, Portable, Space-Saving
SuperBase 1000M is 62% smaller than similar brands on the market. When you hit the road, you’ll find that it’s very easy to carry and fits comfortably in the cabin of your car, so you have more space for the things you need. Weighing less than 18 pounds, SuperBase 1000M is our most portable SuperBase yet.
Hassle-free Charging in Your Car
With this tiny dimension, you can easily put it in your armrest box or passenger seat, fully charged through a 12.6V/8A car port ≤ 10 hours.
Gets Along with Your Devices
SuperBase M may be small, but it’s got plenty of connections for your favorite devices. With pure sine-wave AC output and multi-protocol USB ports, you can easily power home appliances and charge handheld essentials at the same time.
1,016Wh/607Wh Capacity
Since SuperBase M doesn't have an internal fan, there's more space inside for a larger battery. That's why other power stations with the same capacity as SuperBase M tend to be larger and heavier. SuperBase M is smaller and lighter, without compromising on capacity.
Psst… Less Than 30dB
Most power stations have fans and other noisy parts that can generate over 60dB of noise. SuperBase M's fanless design allows you to enjoy portable power without the noise.
Bright LED Lamp
SuperBase M’s back panel features a 10W LED lamp with four brightness levels and an emergency signal mode. A fully charged SuperBase 1000M can power the built-in lamp for up to a week.
Portable Sustainable Energy
With Zendure 100W or 200W solar panels, you can supercharge your next camping trip or outdoor adventure while taking advantage of sustainable energy. Whether you’re charging your laptop or brewing your morning coffee, a solar package with SuperBase M will keep you going.
Zendure SuperBase M Frequently Asked Questions
Zendure SuperBase M Frequently Asked Questions
How does this product dissipate heat safely without a fan?
The product uses high-frequency circuitry that generates less heat overall, and the aluminum enclosure helps dissipate heat into the air, for quiet operation.
How long can the product be stored?
If you are storing this product for more than three months, make sure the battery is at least 50% charged. Every six months, fully drain and recharge the battery to prolong the service life of the internal battery.
How long does it take to fully charge this product?
When using mains/solar panels, and the car charging port/USB Type-C charging simultaneously, it takes about 2.9 hours to charge at full speed.--When charging with mains power, it takes about 5.5 hours to fully charge.--When using the car charging port, it takes about 5.1 hours.--When charging with USB Type-C, it takes about 6.4 hours to fully charge.--When charging with solar panels, it can vary. As a baseline, a 150W solar array receiving 750W/m2 would take about 4.2 hours.
--Note: the above figures are reference approximations from laboratory testing.
Can I charge this product with solar power and the car charging port together?
You can charge this product with both at the same time, to reduce charging time.
Can the product be discharged (outputs used) while charging?
This product supports discharging while charging. When the output power is greater than the charging power, the charge level will decrease over time. When the charge level is very low, the output ports will be deactivated.
Can this product handle extreme temperatures?
This product can be charged at up to 45°C, and discharged at up to 40°C.
Will this product shut down automatically?
This product will only shut down automatically if the charge level is very low or one of the safety mechanisms has been triggered.
How much displacement of the product car can start when starting?
The product starting principle is to charge the car battery, 12V system can be used, the displacement is not limited.
What does it mean when the screen shows “SUS”?
The screen will display “SUS” to indicate that the temperature is too high or too low to charge safely, so the product will not accept a charge.
If electricity is cut off while it's being used in pass through mode, how long does it take to switchover to the battery as a power source?
If it is running in charge-through mode and the power source is disconnected or turned off, the device will switch to battery power almost instantaneously.
