Equipped with PowerControl and PowerAssist technology, the MultiPlus-II intelligently manages available power from generator, shore, or grid sources, preventing overload by supplementing peak demands with battery power when needed – and automatically recharging when demand drops. An external current sensor extends input management up to 100A, enabling greater flexibility in power-limited environments.
Built to meet UL 458 certification standards, this unit ensures safe, efficient, and reliable performance in both mobile and stationary applications – delivering intelligent power management and uninterrupted energy wherever you need it.
Ships From: Texas, USA
Warranty: 5 Years
Support: Lifetime USA-Based Tech Support
Compatibility
Best-Fit Applications:
RVs and camper systems
Marine and boating applications
Off-grid and solar energy systems
Backup power and hybrid installations
System Compatibility:
Compatible with 24v HUSKY2 INV battery system
Compatible with Victron solar charge controllers (MPPT)
Works with grid-tie inverters and AC-coupled systems
Supports generator, shore power, and grid input
Installation Compatibility:
Designed for mobile and off-grid installations
Integrates with Victron GX devices for advanced monitoring
UL 458 compliant for RV and mobile applications
Key Features
-
3000VA Pure Sine Wave Inverter – Clean, stable AC power for sensitive electronics
-
70A Battery Charger – Fast and efficient battery charging
-
PowerControl Technology – Prevents overload by managing incoming AC limits
-
PowerAssist Technology – Boosts output using battery during peak demand
-
Up to 100A Input Management – With external current sensor
-
Seamless Power Switching – Uninterrupted operation during source changes
-
Wide System Integration – Compatible with solar, grid, and generator setups
-
Remote Monitoring Ready – Works with Victron GX ecosystem
-
UL 458 Certified – Safe for RV and mobile use
-
High Efficiency & Reliability – Built for demanding environments
A powerful and intelligent inverter/charger solution built for seamless integration, efficient energy management, and reliable performance across mobile, marine, and off-grid power systems.
Downloads & Specifications
Battery Voltage:24VDC
Rated Power:3000 VA / 2400 W
Peak Power:5500 W
Parallel Capacity:Yes
Nominal Output Voltage RMS:N/A
Output Frequency:60 Hz ± 0.1%
AC Voltage Regulation:120 VAC ± 2%
Inverter Efficiency (Peak):94%
Waveform:Pure Sine Wave
Transfer Time:N/A
Voltage:120VAC
Selectable Voltage Range:90-140 VAC
Frequency Range (Auto-Sensing):45 – 65 Hz
Max. Charging Current:70A
Weight:42 lbs
Depth:5.8 in
Width:10.9 in
Height:21.1 in
