Product details
Jackery 5000 Plus LiFePO4 Battery | 5040Wh Capacity | 7200W Output | 134.5lb | 3.5 hours via AC | 11-Year Battery Lifespan
Handles Even the Big Appliances
Run major home appliances with 7200W of rated power (14,400W surge). Supports both 120V and 240V for powerful more devices, even a 5-ton AC for comfortable indoor temperatures or a water heater for a hot shower.
Backup That Lasts for 13 Days
A 5040Wh capacity, expandable up to 60kWh — enough to keep your home running through an extended outage, not just overnight.
More Power From the Sun
Compatible with both high-and low-voltage solar panels, recharge in about 2 hours with up to 4000W input, staying powered in home or RV.
Protect your essential circuits smartly
Pair with the Jackery 60A Smart Transfer Switch to power up to 12 circuits at 120V or 6 circuits at 240V.
11 Years of Reliable Power
Less than $1 a day for up to 11 years of peace of mind, powered by durable LiFePO₄ battery cells and ChargeShield™ 2.0 protection.
Outages Won't Interrupt a Thing
True 0ms UPS switching keeps computers, appliances, and critical devices running without interruption.
Kits details
Basic Kit
Explorer 5000 Plus
Plug-and-play backup power to keep your essentials running during outages.
Includes:
- 1 x Explorer 5000 Plus
- 1 × AC Charging Cable
- 1 × MC4 Wrench
Recommended Kit
Explorer 5000 Plus + SolarSaga 500 X × 2
Pair with solar panel for daytime solar top-ups, extending backup power.
Includes:
- 1 x Explorer 5000 Plus
- 1 × AC Charging Cable
- 1 × MC4 Wrench
- 2 × SolarSaga 500 X
Advanced Kit
Explorer 5000 Plus + Smart Transfer Switch
Connect directly to home circuits for effortless, seamless power switching.
Includes:
- 1 x Explorer 5000 Plus
- 1 × AC Charging Cable
- 1 × MC4 Wrench
- 1 × Smart Transfer Switch
Complete Kit
Explorer 5000 Plus + SolarSaga 500 X × 2 + Smart Transfer Switch
Combine circuit-level backup with solar energy for independent power.
Includes:
- 1 x Explorer 5000 Plus
1 × AC Charging Cable - 1 × MC4 Wrench
- 1 × Smart Transfer Switch
- 2 × SolarSaga 500 X
Additional Kit
Explorer 5000 Plus (10kWh) + Smart Transfer Switch
Power more, for longer-integrating circuit-level backup with boosted capacity in one complete solution.
Includes:
- 1 x Explorer 5000 Plus
- 1 × AC Charging Cable
- 1 × MC4 Wrench
- 1 × Smart Transfer Switch
- 1 × Battery Pack 5000 Plus
- 1 x Expansion Cable
Flagship Kit
Whole-Home Backup Kit 5000 Plus (20kWh)
Power your whole-home backup for up to a week, reducing reliance on the grid.
Includes:
- 2 x Explorer 5000 Plus
- 2 × AC Charging Cable
- 2 × MC4 Wrench
- 1 × Smart Transfer Switch
- 2 × Battery Pack 5000 Plus
- 2 x Expansion Cable
Specs
Ports & Dimensions





Tech Specs
Jackery Explorer 5000 Plus
Battery
|
Capacity
45Ah/112V DC (5040 Wh)| |
Cell Chemistry LiFeP04 |
|
Cycle life 4000 cycles to 70%+ capacity |
|
General
| Weight
About 134.5 Ibs (61 kg) |
Discharge Temperature 5~113°F(-15~45°C) |
|
Dimensions 16.5x15.5×25 in/41.8×39.5×63.5 cm |
Warranty 5 Years |
|
Charge Temperature 32~113°F (0~45°C) |
|
Output Ports
|
AC Output (4x) 120V, 20A, 2400W (1x) NEMA L14-30R/14- 50: 120V/240V~60Hz, 30A, 7200W Max |
AC Total Output 7200W Max, 14400W Surge |
|
USB-C Output (2x) 100W Max, 5V-3A, 9V-3A, 12V-3A, 15V-3А, 20V=5A |
USB-A Output (2x) 18W Max, 5-6V-3A, 6-9V-2A, 9-12V=1.5A |
|
Cigarette Lighter Port 12V=10A |
AC Expansion Port 240V~60Hz, 30A, 7200W |
|
DC Expansion Port 80.5V-126V-41A Max |
|
Input Ports
|
Charge Mode AC Input
120V~60Hz, 15A Max |
Bypass Mode AC Input/Output 120V~60Hz, 12A Max; 240V~60Hz, 16.7A Max |
|
AC Expansion Port (Input) 240V~60Hz, 16.7A Max |
DC Input DC Expansion Port (Input) : 80.5V-126V-98A Max |
|
High-PV 135V-450V-15A Max |
Low-PV (2x) DC 8mm Ports; 16V-60V=10.5A Max, Double to 21A/1200W Max ; 11V-16V(Working Voltage)=8A Max, Double to 8A Max |
Charging Time
|
AC Adapter
3.5 Hours |
Car Adapter (12V) NO |
|
Solar Charging 6.5-8.5 Hours |
|
Other Specifications
| UPS
Backup UPS: <20ms, Online UPS: Oms |
Inverter Topology Non-isolated |
|
Power Factor ≥0.98 |
Entire Unit Type 1 |
Jackery Battery Pack 5000 Plus Specs
General |
|
|
|
Capacity 45Ah/112V DC (5040 Wh) |
Weight About 81.57 Ibs (37 kg) |
Dimentions 16.5 × 13.5 × 13.2 in / 41.8 × 34.4 × 33.6 cm |
|
Battery Lifecycles 4000 cycles to 70%+ capacity |
Warranty 5 Years |
Charge Temperature 32~113F (0~45°C) |
|
Discharge Temperature 5~113°F (-15~45°C) |
||
Port |
||
|
DC Extension Ports (lutput) 80.5V-126V-41A Max |
DC Extension Ports (Output) 80.5V-126V-98A Max |
|
Battery Pack 5000 Plus User Manual
Jackery Smart Transfer Switch Specs
| SPECIFICATIONS | Jackery Smart Transfer Switch |
|
Model No. |
JA-TS02A |
|
AC Voltage (Nominal) |
120V/240V~ 60Hz |
|
Feed-In Type |
Split Phase |
|
Maximum Input Current |
100A Grid / 60A Power Station |
|
Maximum Output Current |
60A Home Load / 33.4A Power Station |
|
Maximum Input Short-Circuit Current |
10KA |
|
Overvoltage Category |
IV |
|
UPS |
≤20ms |
|
Enclosure Type (Distribution Panel) |
NEMA Type 1 |
|
Number of Load Branches |
12 |
|
Main Circuit |
2 AWG |
|
Branch Circuit |
14 AWG 12 AWG 10 AWG |
|
Communication |
Wi-Fi and Bluetooth |
|
Operating Temperature |
-20°C~40°C (-4°F~104°F) |
|
Weight |
About 25.57 lbs/11.6 kg |
|
Dimensions |
22 x 14.7 x 7.87 in/56 x 37.4 x 20 cm |
|
Package List |
Jackery Smart Transfer Switch Power Input/Output Cable User Manual |
|
User Manual |
|
|
APP User Manual |
|
|
Jackery Smart Transfer Switch Installation Training |
|
|
Jackery Smart Transfer Switch Removal Training |
SolarSaga 500X
General
|
Weight 22.05 Ibs ‡ 2.20 Ibs (10.5 kg‡0.5 kg) |
Protection Class Against Electric Shock Class I| |
|
Waterproof |P68 |
Operating Temperature Range -40~185°F (-40~85°C) |
|
Warranty 5 Years |
|
Solar
|
Maximum System Voltage 600V DC |
Maximum Reverse Current 15A |
|
Bifaciality Coefficient (back/front) Pmax>80%, Voc>97%, Isc>80% |
Voltage Temperature Coefficient -0.26%/°C |
|
Power Temperature Coefficient -0.32%/°C |
|
STC (1000W/m, 25°C, AM 1.5)
|
Peak Power (Pmax) 500W=5% |
Open Circuit Voltage (VOC) 48.5V+5% |
|
Short Circuit Current (Isc) 13.02A+5% |
Power Voltage (Vmp) 41.7V=5% |
|
Power Current (Imp) 12.0A+5% |
BNPI (Front 1000W/m, Rear 135W/m, 25°C, AM 1.5)
|
Peak Power (Pmax) 545W=5% |
Open Circuit Voltage (Voc) 49.2V+5% |
|
Short Circuit Current (Isc) 13.86A+5% |
Power Voltage (Vmp) 42.5V‡5% |
|
Power Current (Imp) 12.84A‡5% |
Dimensions
|
Folded Around 39.21 × 20.71 × 3.82 in (996 × 526 x97mm) |
Unfolded Around 98.15 × 39.21 × 11.57 in (2493 × 996 x 294mm) |
