EcoFlow| Power Kits 5kVA 48V Power System

Name: EcoFlow| Power Kits 5kVA 48V Power System
Brand: EcoFlow
SKU: 30A-RV-Kit
Price: 8246.0 USD
Availability: InStock

$8,246.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Choose Your Kit 30A RV Kit 50A RV Kit Auto Kit

Quantity

· High 5kVA output power, to run 2 × 13500 BTU rooftop a/c units at the same time

· As quiet as 48 dB¹, a volume lower than a quiet office

· 45kWh capacity for up to 7 days off-grid

· 4 diverse charging methods: shore power, solar, vehicle alternator, and generator.

· Charge 11kWh in only 1 hour

· Utilize free energy, 0 upkeep costs

· App & screen smart control

· Compact & light, stores easily

Solutions for All Types of RV

Whether you're replacing the electrical equipment in your vehicle or building a system from scratch, the Power Kits plug-and-play system lets you customize every component to meet the needs of your vehicle and your getaway.

PowerLuxe

Suitable for luxurious RV travel in Class A and Class C motorhomes, the EcoFlow PowerLuxe solution ensures comfort and a steady energy flow for your entire motorhome. Its advanced 48V electrical architecture offers industry-leading safety and efficiency. For extended road trips, store up to 45kWh of power and generate tremendous amounts of energy from solar and alternator, for ultimate on-the-go comfort.

PowerSwift

This safe, high-performing, compact system is perfect for adventurers and van life enthusiasts who demand unlimited power without a bulky battery system. Ideal for off-grid journeys, the EcoFlow PowerSwift solution can be tailored to fit the lifestyle of a compact van owner. With its intelligent and efficient design, this solution delivers super fast charging and smart control over your power.

PowerTrail

This versatile solution is perfect for RV power system upgrades. Whether you are looking for a powerful lithium battery or simply adding more solar power to your RV, the EcoFlow PowerTrail solution delivers robust, efficient power with smart control features. Boost your RV's energy storage to meet more outdoor power needs.

Meet All Your Power Needs

Run 2 × 13500 BTU RV A/C Units

With up to 4000W output and 8000W surge power, the Power Kits 5kVA system can simultaneously run 2 × 13500 BTU RV air conditioners and other high-powered appliances, like air fryers and space heaters, without the need for a soft starter.

Keep the Peace

X-Quiet volume of only 48 dB[1]

With a volume as low as 48 dB at a 50% wattage load, run your Power Kits system all day and night on any campground without worrying about disturbing the neighbors.

Stay Full of Energy

Power on for up to 7 days

With up to 45kWh energy storage and 4 unique charging methods, stay charged while you're on the road no matter how long you're away.

4 unique charging methods

Rain or shine, at home or on the go, there's always a charging option.

Solar Power

Up to 4800W solar input capacity, fully charge a 5kWh battery in almost 1 hour.

Shore Power

Use shore power for a 4000W charge and top up a single 5kWh battery in only 1.5 hours.

Vehicle Alternator

Combine all charging methods to reach the maximum charging capacity.

Smart Generator

Plug in your EcoFlow Smart Generator (Dual Fuel) and fully charge a 5kWh battery in 1.6 hours with an input of 3.2kW.

1-Hour to Fully Charge

With DC integrated charging, which includes a Power Hub, AC shore power, and Power Dock, you can recharge a massive 20kWh in 1.6 hours!

Stay in Charge with Smart Power

Full-Vehicle Control on One Screen

Track your entire vehicle's power and water usage right from your smartphone or EcoFlow PowerInsight.

Intelligent Monitoring & Control

Power Kits integrates water, electricity, and access control systems for smart vehicle monitoring. It offers remote control of charging and discharging, independent management of 16 DC circuits, and reads power usage for each circuit and total charging/discharging amounts.

Multi-Device & Screen

Seamlessly track data across multiple devices and screens, including 2 monitors and the EcoFlow app.

Customize & Automate

Set smart always-on tasks, including vehicle battery auto-charging, to ensure your batteries are always charged.

Safe & Reliable

Our Tech in One System

Durable Structure

Our industry-first CTC (cell-to-chassis) process integrates the battery shell and internal components into a single, robust structure. This innovative design offers higher strength, external security, and improved drop resistance.

On Guard 24/7

Our X-Guard BMS (Battery Management System) algorithm provides around-the-clock protection. Covering up to six monitoring and safeguard measures, including low temperature, over-discharge, overcharge, high temperature, short circuit, and overcurrent, it ensures a fail-safe recovery.

Safety, Certified

Experience reliable RV power and safety with our UL1973-certified 48V LFP batteries, UL458-certified Power Hub and UL67-certified distribution panel.

50% Lighter, 50% More Compact

Designed with small spaces in mind, Power Kits uses half the space and weighs 50 lb less than comparative solutions. It's a convenient, plug-and-play system that leaves more time for off-grid adventures.

Simple Assembly

We made our modular system plug-and-play so you can quickly customize your van power whenever you want. Simply stack a battery to increase capacity or plug in a solar panel for faster charging.We've got experts on hand to guide you through the installation process or put you in touch with authorized and reputable installers.

Tech Specs

Power Hub

Net weight (lbs)	31
Net Weight (kg)	14
Dimension (inch)	11.8 x 18.9 x 5.5 in（Height x Width x Depth)
Dimension (cm)	30 x 48 x 14 cm (Height x Width x Depth)
Tests and Certifications	UL Standard, FCC,ICES
Wi-Fi	✓
Bluetooth	✓
Mobile App	✓
AC Main Output/Frequency	Pure Sine Wave, 3600W (Surge 7200W), 120V, 50Hz/60Hz
DC Main Output	13.6V/70A 1000W Max; 26.4V/60A, 1600W Max
AC Main Input	X-Stream Fast Charging 3000W Max, 30A Max
AC Main Input Voltage/Frequency	100-120V, 50Hz/60Hz
Solar Charging Input	15-150V 30A, 1600W Max
Alternator Charging Input	13V-60V, 60A, 1000W Max
Operating Temperature	-13°F-140°F
Discharge Temperature	-13°F-140°F
Charge Temperature	-13°F-140°F
Storage Temperature	-13°F-140°F

5kWh LFP Battery

Capacity	5120Wh (51.2V, 100Ah)
Cell Chemistry	Lithium Iron Phosphate
Cycle Life	~3500 Cycles up to 80% Capacity
Net weight (lbs)	90
Dimension (inch)	11.8x19.7x10.2in (Height x Width x Depth)
Dimension (cm)	30x50x26cm (Height x Width x Depth)
Net Weight (kg)	41
Protection Level	IP54
Tests and Certifications	UL Standard, FCC, CE, E-Mark, UKCA, UN38.3, RCM, PSE
Storage Temperature (F)	-4°F–140°F
Storage Temperature C	-20°C–60°C
Operating Temperature (F)	-4°F-122°F
Operating Temperature C	-20℃-60℃

Power Kit Console

Touch Screen (Diagonal Measurement)	7 Inch (6x3.4in) (Width x Height)
Power Supply Voltage	12 VDC
Operating Temperature C	-20℃-60℃
Operating Temperature (F)	-4°F-140°F
Dimension (inch)	4.5x8x0.9in (Height x Width x Depth)
Dimension (cm)	113.3x204.5x22.35mm (Height x Width x Depth)
Net weight (lbs)	1
Net Weight (kg)	0.45
Tests and Certifications	UL Standard, FCC,ICES,CE,UKCA,E-Mark,RCM,TELEC,KCC

AC/DC Smart Distribution Panel

AC Main Input	30A Max. 120V, 3600W
DC Main Input	70A Max
AC Output	6 AC Positions, 20A Max Each
DC Output	12 Fused DC Positions (6 Positions Controllable via Power Kit Console & App)
Operating Temperature C	-25℃-60℃
Operating Temperature (F)	-13°F-140°F
Dimensions	8.3x13.9x3.9in (Height x Width x Depth)
Net Weight(lbs)	5.7lbs
Net Weight (kg)	2.6
Protection Level	IP21
Tests and Certifications	UL Standard, FCC,PSE

View full details

EcoFlow User Manuals

EcoFlow Power Kit 4 Charging Methods

FAQ

Can I use my own non-EcoFlow batteries?

Power Hub is not compatible with third-party batteries.

How many DC circuits can the 30A/50A AC/DC Smart Distribution Panel control?

It can control 16 circuits, max. 30A for F1–F13, and max. 50A for F14–F16

Can a 30A/50A AC/DC Smart Distribution Panel connect to 120V/240V AC?

Yes. The input specification is max. 50A, 120/240V, 60 Hz.

What is purpose of the Power Dock Battery 3-pin port/Multi Connection? row

1. Connect batteries in parallel
2. Connect an EcoFlow Smart Generator to recharge the system
3. Connect an EcoFlow Delta Pro Smart Extra Battery/Delta 2 Max Smart Extra Battery

What does Power Dock do?

1. Three batteries connected in parallel can be connected to a Power Dock connected to one port of Power Hub.
2. There are two DC outputs that can power 48V appliances. The specification is 40–60V⎓55A and the app or Power Kit Console can be used for control and data monitoring.
3. Connect an external manual switch to disconnect the 48V DC connection between the battery and Power Hub.

Does Power Hub have GFCI protection?

The user can connect an external GFCI protector if required. The internal GFCI function of Power Hub 5kVA is always on and no special operation is needed to enable GFCI protection.

What is the temperature range for normal operation of Power Kits?

Optimal operating temperature: 20°C–40°C
Optimal recharge temperature: -25°C to 60°C. Recharging starts to derate above 40°C.
Optimal discharge temperature: -25°C to 60°C. Discharging starts to derate above 40°C.

Power Kits update precautions

Use Power Kit Console for synchronous updating of Power Hub and Power Kit Console. If you use the app to update, Power Kit Console cannot be updated, so we recommend using Power Kit Console to update.

Power Hub installation precautions in a confined space

Be sure to install a cooling fan when installing Power Hub in an enclosed space, so as not to compromise the performance and service life of Power Hub.

Power Hub installation precautions

Drill holes before installing the upper and lower brackets. Ensure that no metal filings or dust get in the device, as these can cause short circuits.

Collapsible rowPurpose of power grid priority

This prevents a poor-quality power grid from affecting appliances when power grid quality is variable. Turning off grid power priority puts it in inverter priority mode, safeguarding output power quality.

X-Fusion (Power Assist)

When in bypass mode (when you recharge and discharge simultaneously, the device automatically enters bypass mode), the X-Fusion feature ensures that all AC output sockets supply optimal power and current.

Can Power Kits be used as UPS?

No. UPSs have a transfer time of 0–20 ms. Power Kits currently take 30 ms and can only serve as EPS.

Can the EcoFlow App monitor and control recharging?

Use the EcoFlow App to monitor energy use, recharging input and to adjust settings, error alarms, etc. Console can also be used to monitor and control Power Kits.

How does Power Hub detect vehicle motion?

Power Kits can utilize a vibration sensor to ensure recharging only occurs when the vehicle is in motion in order to safeguard the vehicle battery.
Default voltage protection is set to 13V (or 26V/52V depending on the battery specification of the alternator). Turn off the idle recharge switch once the vehicle ignition is off if you wish to maintain the vehicle battery close to 14V.

Priority of the three recharging modes (PV, ALT and AC)

PV>AC>ALT>Smart Generator. Lower priority sources for recharging automatically stop working when the recharging power exceeds what the battery needs to recharge.

Battery heating

Manual discharge heating function: Manually discharge and heat the battery via the Console or app when the battery temperature <0°C and SOC>50%. When the battery SOC ≤ 30% or the battery temperature is higher than 10°C, the battery discharge heating is automatically switched off.
Automatic recharge heating function: Automatic heating on recharge
In order to extend the battery life and maintain optimal performance, it will continuously heat the battery up to the optimal operating temperature automatically (BP2000 — 18°C, BP5000 — 23°C) when there is sufficient input power (>250W is needed to heat a battery). The battery charge heating is automatically switched off when power is insufficient for heating so as to prioritize recharging.

What is the maximum DC output of the Power Hub battery port?

40–57.6V⎓55A

What is Power Hub's maximum bypass current?

50A

What is Power Hub's maximum recharging power?

ALT1 & PV1: 4000W
ALT2/3 & PV2/3: 1600W
AC: 4000W
The maximum recharging power for the device as a whole is 11kW
