EcoFlow|175W Rigid Solar Panel

Increase the efficiency of your solar panel by facing it directly at the sun without any obstructions. Remember to be careful when handling your solar panel because damaged cells provide less power.

Yes, if the only thing between it and the sun is transparent, but it won’t charge as well compared to being outside. You can compare the difference by looking at the input section of your power station’s LCD screen.

Yes, but it is not recommended. Different energy storage controllers have requirements and restrictions on the output of solar panels. When solar panels with different current values are used in series, they will be limited, resulting in the inability to release the output power and even the short-board effect of 1+1<2

EcoFlow TOPcon solar panel has a next-level solar conversion efficiency rate of 25%, significantly higher than the 18%-20% conversion efficiency of many traditional solar panels. It maintains high power output even in low light and high-temperature environments, making it perform better in various weather conditions. It has an IP68 waterproof rating, ensuring greater durability and reliability, with a lifespan of up to 30 years.

On a sunny day without clouds and direct sunlight, the power range of a 175W solar panel is between 130–145W (this data is obtained under the conditions of irradiance of 800–900W/m2 and the panel surface at 60°C (140°F)). The nominal data of the solar panel is obtained by testing under the conditions of AM1.5, meteorological conditions of 1000W/m2, and panel surface temperature of 25°C (77°F). A power close to the nominal value can usually be reached at midday on a sunny day in winter.

Yes. There can be a lot of dust and foreign objects on the surface of the solar panel after the panel has been used outdoors for a long time, which block the light to a certain extent, reducing the power output. Regular cleaning can help keep the surface of the solar panel clean and free from obstructions and generate a higher power output.However, when cleaning, be careful to wipe the surface with soft materials to prevent hard materials scratching the surface of the panel and affecting the output.

It is suitable for installation on the roofs of Class B Vans, Class C vehicles, and trailers.

You should choose the right controller or inverter based on your specific usage to ensure efficient storage and use of electricity.

This solar panel features a high-voltage design and uses an LFB-40 interface. It can be connected in series to save on wiring.

The LFB-40 interface is a common DC power output connector used for solar panels. It primarily facilitates power transmission between portable solar power generation equipment and devices like charging controllers, energy storage units, and power banks.

This interface supports a maximum current of 40A, meeting the standard 30A current capacity. It can reliably handle high currents, preventing overheating or damage. It can be connected in series, allowing up to 10 130W solar panels to be linked together. Additionally, it has a locking mechanism to ensure the solar panel remains secure and does not detach due to vibrations when installed on a vehicle.

Regularly clean the panels with clean water or a damp cloth to prevent dust from reducing their efficiency. Avoid using hard objects to scratch the surface to prevent damage. Annually check the wire connections to make sure they are secure, as poor connections can affect charging.

Solar panels require sunlight to generate electricity. They can still produce a small amount of power on cloudy days, but with reduced efficiency. At night or in extreme weather conditions, their power generation capacity will significantly decrease or stop, so using energy storage equipment is recommended.

Yes, but their efficiency will be lower. Winter has shorter daylight hours, and low temperatures can affect the performance of the batteries. It is advisable to regularly check if the solar panels are covered by snow during winter to maintain good power generation capacity.

Typically, they can endure temperatures ranging from -40°C to 85°C, though extended exposure to high heat might reduce their efficiency.

Solar panels are quite light, with each panel weighing around 5.6 kg, so they generally don't add much weight to the vehicle.
