50W Foldable Solar Panel

Regular price$140.80
/
Tax included. Shipping calculated at checkout.

Get 5% off On Order $500 & Up Use Code OnlyEcoPowerit | Ends:

  • Free Shipping Within The USA
  • Ships in 5/7 business days
  • Inventory on the way

ACOPOWER 12V 50 Watt Portable Solar Panel Kit W/ 5A Charge Controller for RV, Boats, Camping

To make your outdoor experience easy, Acopower developed a space saving PV solar panel suitcase for your outdoor needs. With the highest efficient cells, the suitcase could supply optimally 300wh each day.


Key Features


  • 50W monocrystalline photovoltaic kit was made of 4 pcs 12.5W solar panels

  • Features ultra lightweight design (92 oz), laptop-like storage size of 14.2x11.4 inch

  • Charges 12V lithium and lead acid batteries, provides a USB 5V output for phones/USB devices when connected to the battery. Features removable charge controller for solar generator, inverter or power station/bank

  • Weather-resistant, water-resistant, industrial-strength PET polymer laminated;





                How to Test the Solar Panel

                Method 1: Use a Multi-meter





                Set your multi-meter to measure DC voltage and put the red probe on the red MC4 cable and the black probe on the black MC4 cable (this is the solar panel’s direct output), make sure the connections are secure. the open-circuit voltage should be displayed on your multi-meter and it should be around 17.6V-23V.

                If you’re not getting something within that range or close to those numbers, you should check and make sure the solar panel is in direct sunlight and that the connections between the MC4 cables and the multi-meter is secure.

                Method 2: Use your Solar Generator

                To test if the solar panel is working with a solar generator with a built-in charge controller, connect the MC4 adapters that came with your solar generator and plug it in to the MC4 cables of the solar panel directly (Bypassing the charge controller). Turn your solar generator on and it should start charging from the solar panel.

                Specifications

                ACOPOWER 80W FOLDABLE SOLAR PANEL

                Module Type:

                4×12.5W

                Open-Circuit Voltage (Voc):

                21.6V

                Short-Circuit Current (Isc):

                2.94A

                Folded size:

                14x11.4x1 in /355×290×25mm

                Weight:

                5.9lbs / 2.66kg

                Maximum Power:

                50W

                Maximum Operating Voltage (Vmp):

                18V

                Maximum Operating Current (Imp):

                2.77A

                Unfolded size:

                14x11.4x1 in /355×290×25mm



                User Manual

                Manual

                Whats in the Box
                • 1 x 50W Foldable Solar Panel
                • 1 x User Manual
                Shipping, Return & Refund


                Shipment processing time
                Usually, shipment would be processed in 48 hours (except holidays and weekends). We do not accept same-day deliver or next-day deliver orders. Insurance is not included; if request, shipping insurance would be added to invoice.
                For less than 70lbs, UPS Ground unless otherwise requested and stated on each order placed.
                For more than 150lbs, Pallet shipping unless otherwise requested and stated on each order placed. Confirmation may be needed before shipping for forklift and liftgate.
                For order weight 70-150lbs, carrier choose is subject to the cost and delivery date.
                Shipment confirmation & Order tracking
                You will receive a Shipment Confirmation email once your order has shipped containing your tracking number(s). The tracking number will be active within 24 hours.
                Damages
                ecopowerit.com is not liable for any products damaged or lost during shipping. If you received your order damaged or lost your package, please contact us within 20 days at info@ecopowerit.com.
                Return Authorization Policy

                1. Merchandise, in good condition, may be returned for in store credit upon inspection.
                2. Customer must call EcoPowerit within 30 days of receipt of merchandise for a Return Authorization (RA) number. All returns follow the warranty polices.
                3. A RA number may only be issued by an Account Manager. A log will be kept of all RA #'s issued. 4. RA numbers must be placed on the outside of the package to be accepted for return.
                4. Prepackaged assortments must be returned in their entirety. No partial assortments will be accepted for returns unless damaged product was shipped.
                5. Calls/Emails for a RA number received after the 30 days from receipt will be subject to a restocking fee. 7. Packing and handling fee is subject to be charged. 8. No cash refunds, credit towards next sale only. 9. Return shipping fee should be taken by dropship partner/reseller if not quality issue.

                Cancellation
                Customers can request a full refund within 24 hours after placing an order on ecopowerit.com. Please note that we will charge a transaction fee if you apply for the refund after 24 hours and before delivery (2.6% for credit card users, 3.6% for PayPal users, 3.5% for Affirm users). Orders purchased after 30 days could not be canceled.

                Warranty Registration
                Panels: The solar panel itself comes with an 18-months workmanship warranty and a 25-year 85% output warranty.
                Accessories: 1-year material warranty


                ACOPower’s products are manufactured to the highest standards in quality and performance and backed by limited warranty protection. Registering your purchase will allow us to contact you and service you more efficiently in the unlikely event that a safety notification is required.
                Click to register your product
                After-sale Service Contact

                • 916-658-3961

                • info@ecopowerit.com
